Here are the standard sheet sizes in metric units:
• 1500 X 1500 mm
• 1500 X 2250 mm
• 1500 X 4500 mm
• 1500 X 1000 mm
• 1000 X 1000 mm
• 1500 X 4000 mm
• 1500 X 2000 mm
• 1300 X 3900 mm
• 1270 X 1270 mm
• 2100 X 3000 mm
• 1500 X 3000 mm
• 2000 X 3000 mm
Thickness
• Metallic – 0.8 mm to 6 mm
• Non Metallic – 0.4 mm to 6 mm
Tolerance
• Length and width – ±5%
• Thickness ≤1.0mm – ±0.1mm
• Thickness ≥1.0mm – ±10%
Organic Fiber-Based Gasket Material with NBR Binder
This advanced gasket material combines organic fibers with a Nitrile Butadiene Rubber (NBR) binder, offering a superior blend of strength, flexibility, and resistance. Organic fibers provide the necessary structural integrity, while the NBR binder ensures excellent sealing performance, especially in environments with oils, fuels, and other lubricants. The resulting material is ideal for use in automotive, industrial, and mechanical applications, where durability and reliable sealing are crucial.
The organic fiber composition enhances compressibility and resilience, allowing the gasket to form tight seals and withstand varying pressures. The NBR binder significantly improves chemical resistance, particularly to petroleum-based fluids, making this gasket material suitable for demanding sealing applications.
Whether used in static or dynamic sealing environments, this composite gasket material offers long-term performance, reduced wear, and enhanced leak prevention. Its ability to maintain a consistent seal under harsh conditions makes it a trusted choice in industries where reliability and durability are key.
