    BJSEAL-EnviGuard EG 5045

    The BJSEAL-EnviGuard 5045 is a high-performance gasket material engineered for applications that demand exceptional thermal stability and resistance to a wide range of substances. Composed of a robust blend of aramid fiber, glass fiber, and rockwool, this gasket material is reinforced with a high-viscosity nitrile butadiene rubber (NBR) binder. The EnviGuard 5045 is designed to perform reliably across varying temperatures, from sub-zero to high-temperature environments, and offers excellent resistance to steam,water, oils, hydrocarbons, and boasts very low gas permeability. This versatile material is ideal for sealing applications that require durability and consistent performance under fluctuating conditions.

    A composite gasket material consisting of Aramid fiber, glass fiber, and rock wool, bound together with a high-viscosity Nitrile Butadiene Rubber (NBR) matrix, engineered for enhanced durability, thermal stability, and resistance to pressure and mechanical stress.

    Here are the standard sheet sizes in metric units:
    • 1500 X 1500 mm
    • 1500 X 2250 mm
    • 1500 X 4500 mm
    • 1500 X 1000 mm
    • 1000 X 1000 mm
    • 1500 X 4000 mm
    • 1500 X 2000 mm
    • 1300 X 3900 mm
    • 1270 X 1270 mm
    • 2100 X 3000 mm
    • 1500 X 3000 mm
    • 2000 X 3000 mm
    Thickness
    • Metallic – 0.8 mmto 6 mm
    • Non Metallic – 0.4 mmto 6 mm
    Tolerance
    • Length and width – ±5%
    • Thickness ≤1.0mm – ±0.1mm
    • Thickness ≥1.0mm – ±10%

    ENVI GUARD 5045_TDS

    Applications:
    • Steam Systems: Ideal for medium-pressure steam applications, providing reliable sealing in boilers, piping systems, and heat exchangers.• Water and Cooling Systems: Suitable for use in plumbing, HVAC, and cooling systems, ensuring effective sealing in environments exposed to water and cooling liquids.
    •Oil and Fuel Systems: Reliable for sealing in automotive, petrochemical,and industrial machinery where exposure to oils and fuels is common.
    • Inert Gas Sealing: Effective in sealing inert gases in industrial processes,providing dependable performance in low-stress conditions.
    • General Industrial Use: Versatile enough to handle a wide range of general-purpose industrial applications where medium pressure and low-stress conditions are present.

    • HVAC Systems
    • Water Treatment Plants
    • Oil & Fuel Handling
    • General Industrial Machinery
    • Automotive Industry
    • Food & Beverage Industry
    • Pulp and Paper Industry
    • Chemical Processing
